We have a solid experience in the cable extrusion sector and in the wire and cable production in general, so we can easily designe and manufacture an innovative cable extrusion solution completely integrated on your existing production line and control system. We also offer you a revolutionary solutions for production increasing due to flexible applications, the best extruder output available on the market, scrap and setup time reduction.
Available Model:
| Model | EXT-70x25Dmm | EXT-75x25Dmm | EXT-80x25Dmm | EXT-90x25Dmm | EXT-100x25Dmm | EXT-120x25Dmm | EXT-150x25Dmm | EXT-180x25DAmm | EXT-200x25Dmm |
| Take up and pay off type | End-shaft type or gantry moving type | End-shaft type or gantry moving type | End-shaft type or gantry moving type | End-shaft type or gantry moving type | End-shaft type or gantry moving type | End-shaft type or gantry moving type | End-shaft type or gantry moving type | End-shaft type or gantry moving type | End-shaft type or gantry moving type |
| Pay off bobbin | Φ1250mm | Φ2000mm | Φ2000mm | Φ2500mm | Φ2500mm | Φ2500mm | Φ3150mm | Φ3150mm | Φ4150mm |
| Tension traction | 500kg | 500kg | 500kg | 800kg | 800kg | 800kg | 3200kg | 3200kg | 3200kg |
| Screw diameter | Φ70mm | Φ75mm | Φ80mm | Φ90mm | Φ100mm | Φ120mm | Φ150mm | Φ180mm | Φ200mm |
| Screw L/D ratio | 25:1 BM | 25:1 BM | 25:1 BM | 25:1 BM | 25:1 BM | 25:1 BM | 25:1 BM | 25:1 BM | 25:1 BM |
| Output | 180kg/hr | 200kg/hr | 250kg/hr | 350kg/hr | 450kg/hr | 550kg/hr | 650kg/hr | 900kg/hr | 1000kg/hr |
| Main power | 37Kw | 55 Kw | 75Kw | 75Kw | 132Kw | 132Kw | 160Kw | 185Kw | 200Kw |
| Outlet wire scope | 5-25mm | 5-30mm | 16-35mm | 16-50mm | 20-80mm | 30-80mm | 50-140mm | 50-140mm | 35-200mm |
| Tractor type | Caterpillar | Caterpillar | Caterpillar | Caterpillar | Caterpillar | Caterpillar | Caterpillar | Caterpillar | Caterpillar |
| Traction force | 800Kg | 800Kg | 1250Kg | 1250Kg | 1600Kg | 2000Kg | 3200Kg | 3200Kg | 3200Kg |
| Cooling device | Single layer U type water trough | Single layer U type water trough | Single layer U type water trough | Single layer U type water trough | Single layer U type water trough | Single layer U type water trough | Single layer U type water trough | Single layer U type water trough | Single layer U type water trough |
| Length of water trough | 16M(Before 4M After 12M) | 18M(Before 4M After 14M) | 18M(Before 4M After 14M) | 18M(Before 4M After 14M) | 22M(Before 4M After 18M) | 20M(Before 4M After 16M) | 28M(Before 4M After 24M) | 28M(Before 4M After 24M) | 28M(Before 4M After 24M) |
| Size of water trough | Φ1250 | Φ2000 | Φ2000 | Φ2500 | Φ2500 | Φ2500 | Φ3150 | Φ3150 | Φ4150 |
| Traction speed | 2.3-100 m/min | 2.3-100m/min | 2.3-100m/min | 2.3-100m/min | 2.3-100m/min | 2.3-100m/min | 5-100m/min | 5-100m/min | 0-100m/min |
